●What is a BMS
●The Role of IGBTs in a BMS
●How to Choose
●Applications of Different Rated Voltages in Energy Systems
Keywords:
BMS, Battery Management System, IGBT, IGBT Chips, 6th-Generation Trench Field Process, Low Vce(sat) Coefficient, CP Test Data, Electric Vehicles, Industrial Inverters, Photovoltaic Inverters, UPS, Rail Transportation, Smart Grids, Wind Power Systems.
A Battery Management System (BMS) is crucial to the safety, efficiency, and service life of battery energy storage systems. It continuously monitors key parameters such as voltage, temperature, current, and insulation resistance. To effectively perform its control and protection functions-particularly in managing charge and discharge cycles and interfacing with the Power Conversion System (PCS)-the BMS relies on advanced power electronics. Therefore, IGBT chips play an essential role in its operation.
IGBTs: Core Components for Efficient Power Control
IGBTs are fundamental components in energy conversion and transmission. Their use in power conversion significantly enhances efficiency and power quality, offering both energy-saving and environmental benefits. In BMS-based energy storage systems, IGBTs-through precise control of electrical energy-directly influence charge/discharge efficiency, response speed, and overall energy consumption, making them essential to improving system performance.
How to Select IGBT Chips for BMSs
IGBT chips have undergone multiple technological iterations, evolving from PT and NPT technologies to the latest FS generation. These advancements have led to thinner chips, lower thermal resistance, and improved junction temperature (Tj) characteristics. The introduction of IEGT, CSTBT, and MPT technologies has further reduced the Vce(sat) coefficient and increased power density. Optimization of surface metal and passivation layers ensures that BMS reliability requirements are fully met.
In a highly competitive market, SHYSEMI’s R&D team is dedicated to delivering high-standard IGBT solutions for BMS energy storage systems. Thanks to their advanced technology and exceptional quality, SHYSEMI IGBT chips have achieved outstanding performance, ranking among the top in China with test results comparable to leading German and Japanese counterparts.
SHYSEMI has established long-term partnerships with globally renowned companies such as Xiaomi, Volkswagen, SAIC, and Changhong-primarily due to the following IGBT wafer advantages:
- 6th-generation Trench Field process
- Tapeout at Huahong Group
- 1700V and 1200V dies of identical size
- Significantly lower Vce(sat) coefficient than comparable domestic products
- Full production wafer CP test data provided
Rated Voltage and Its Applications in Energy Systems
SHYSEMI IGBT chips offer advantages such as compact size, high power density, high reliability, and cost efficiency. The product line covers a full range of voltage ratings-from low to high-to meet every power level requirement in energy systems:
600V Reverse-Conducting FS-IGBTs: Suitable for medium- and low-voltage applications such as consumer electronics, white goods, and automotive electronics, providing solutions for compact and high-efficiency power systems.
600V–1700V IGBT Chips: Represent the core voltage range for BMS energy storage systems, widely used in electric vehicles, industrial drives, photovoltaic inverters, UPS, and EV/HEV motor control.
IGBT Chips with High Voltage of 1700V and Above: Designed for large-scale energy infrastructure such as rail transportation, smart grids, and wind power systems, demonstrating SHYSEMI’s technological strength in high-end power semiconductors.
The consistent size of the 1200V and 1700V wafers provides designers with flexible options for creating compact and efficient power stages.
