[ SYIM05M50BTX ] 600V 5A, 3-phase IPM with integrated MOSFETs, drivers
RDS(on)@Typ.Tj=25°C: 1.3
Pin No. : 23
SHYSEMI’s SYIM05M50BTX IPM integrates a three-phase full-bridge topology with built-in MOSFETs, gate drivers, and protection functions, delivering high reliability and simplifying motor drive design.
This IPM is ideal for small inverter-driven applications such as air purifiers and dishwashers.
Pin No. : 23
SHYSEMI’s SYIM05M50BTX IPM integrates a three-phase full-bridge topology with built-in MOSFETs, gate drivers, and protection functions, delivering high reliability and simplifying motor drive design.
This IPM is ideal for small inverter-driven applications such as air purifiers and dishwashers.
More Details
Applications:
- Frequency converter
- Air Conditioning compressor
- Air cleaner
- Dish washer
- Cooker hood
Features:
- Integrated 6 fast recovery power MOSFETs (500V/5A)
- Integrated high voltage gate drive circuit
- Compatible with 3.3V & 5V input signal,effective at high level
- Integrated temperature output
- Built-inquick recovery bootstrap diode
- Insulation class 1500Vrms / min
- Integrated bootstrap functionality
- High reliability and thermal stability,good parameter consistency
Internal Electrical Schematic:
![[ SYIM05M50BTX ] 600V 5A, 3-phase IPM with integrated MOSFETs, drivers](http://custom-images.strikinglycdn.com/res/hrscywv4p/image/upload/c_limit,fl_lossy,h_9000,w_1200,f_auto,q_auto/23234143/112556_63345.png)
